10A/20A/30A 12V/24V/48V PWM Solar Regulator | 12V/24V Auto Adaptation | Solar Panel Voltage Regulator
■ Solar Panel Regulator Feature
1 LCD display PV charge, battery and DC loading condition.
2 Protection against over charge, over discharge, over load and anti-thunder.
3 PWM charging mode, DC mode save cost.
4 12/24V auto adaptation.
5 Available in black and blue.
■ Solar Panel Regulator Specification
|Rated System voltage||12/24V(auto recognition)，48V|
|PV input voltage range||12V System: 15V-44V；24V System: 30V-44V；48V System: 60V-88V|
|Max PV Input Voltage
(At the lowest temperature)
|12V/24V System：50V; 48V System：100V|
|PV Array Maximum Power||12V System：140W(10A)/280W(20A)/420W(30A)/560W(40A)/700W(50A)/840W(60A;
24V System: 280W(10A)/560W(20A)/840W(30A)/1120W(40A)/1400W(50A)/1680W(60A);
48V System: 560W(10A)/1120W(20A)/1680W(30A)/2240W(40A)/2800W(50A)/3360W(60A)
|Battery type||Lead acid battery, deep cycle battery, gel battery etc(Battery type base on user charge specification)|
|Floating voltage||13.8V/ Single battery|
|Charge voltage||14.2V/Single battery|
|Charging protection voltage||17V/Single battery|
|Battery overdischarge voltage||10.5V/Single battery|
|Charging mode||PWM pulse width control|
|Charging method||Three stages ：constant current; constant voltage; floating charge|
|No low loss||<5mA|
|Charging circuit voltage drop||≤0.20V|
|Disharge circuit voltage drop||≤0.15V|
|Thermal method||Natural heat dissipation|
|Type of mechanical protection||IP20|
|Elevation||＜5000m，(Less solar panel when exceed 2000m)|
|Protect the circuit||over-charge, over-discharge, short circuit , over-load and photovoltaic reverse connection protection|
|Machine size (L*W*Hmm)||152*97*42|
|Package size (L*W*Hmm)||160*106*48(1PC)/ 420*340*340(48PCS)|
|Note: All specifications are subject to change without prior notice|
